| 規格 | 齒數 | 節徑 |
外徑 |
L |
| 10MXL100 | 10 | 6.47 | 5.96 | 100 |
| 11MXL100 | 11 | 7.11 | 6.61 | |
| 12MXL100 | 12 | 7.76 | 7.25 | |
| 13MXL100 | 13 | 8.41 | 7.90 | |
| 14MXL100 | 14 | 9.06 | 8.55 | |
| 15MXL100 | 15 | 9.70 | 9.19 | |
| 16MXL100 | 16 | 10.35 | 9.84 | |
| 17MXL100 | 17 | 11.00 | 10.49 | |
| 18MXL100 | 18 | 11.64 | 11.14 | |
| 19MXL100 | 19 | 12.29 | 11.78 | |
| 20MXL100 | 20 | 12.94 | 12.43 | |
| 21MXL100 | 21 | 13.58 | 13.08 | |
| 22MXL100 | 22 | 14.23 | 13.72 | |
| 23MXL100 | 23 | 14.88 | 14.37 | |
| 24MXL100 | 24 | 15.52 | 15.02 | |
| 25MXL100 | 25 | 16.17 | 15.66 | |
| 26MXL100 | 26 | 16.82 | 16.31 | |
| 27MXL100 | 27 | 17.46 | 16.96 | |
| 28MXL100 | 28 | 18.11 | 17.60 | |
| 30MXL100 | 30 | 19.40 | 18.90 | |
| 32MXL100 | 32 | 20.70 | 20.19 | |
| 36MXL100 | 36 | 23.29 | 22.78 | |
| 40MXL100 | 40 | 25.87 | 25.36 | |
| 44MXL100 | 44 | 28.46 | 27.95 | |
| 48MXL100 | 48 | 31.05 | 30.54 | |
| 50MXL100 | 50 | 32.34 | 31.83 | |
| 60MXL100 | 60 | 38.81 | 38.30 | |
| 70MXL100 | 70 | 45.28 | 44.77 | |
| 72MXL100 | 72 | 46.57 | 46.06 | |
| 80MXL100 | 80 | 51.74 | 51.24 | |
| 84MXL100 | 84 | 54.33 | 53.82 | |
| 96MXL100 | 96 | 62.09 | 61.59 | |
| 100MXL100 | 100 | 64.68 | 64.17 | |
| 12MXL100 | 120 | 77.62 | 77.11 |
| 規格 | 齒數 | 形狀 | 節徑 | 外徑 | W | L | K | X | 輪彀直徑 | 內孔 | 檔邊外徑 | 檔邊內徑 | 檔邊型號 |
| 20MXL | 20 | C/A | 12.94 | 12.43 | 11 | 16 | 7 | - | 9 | 6 | 18 | 11 | F-101811 |
| 21MXL | 21 | C/A | 13.58 | 13.08 | 11 | 16 | 7 | - | 9 | 6 | 18 | 11 | F-101811 |
| 22MXL | 22 | C/A | 14.23 | 13.72 | 11 | 16 | 7 | - | 9 | 6 | 18 | 11 | F-101811 |
| 23MXL | 23 | C/A | 14.88 | 14.37 | 11 | 16 | 7 | - | 10 | 6 | 20 | 12 | F-102012 |
| 24MXL | 24 | C/A | 15.52 | 15.02 | 11 | 16 | 7 | - | 10 | 6 | 20 | 12 | F-102012 |
| 25MXL | 25 | C/A | 16.17 | 15.66 | 11 | 16 | 7 | - | 10 | 6 | 23 | 12 | F-102312 |
| 26MXL | 26 | C/A | 16.82 | 16.31 | 11 | 16 | 7 | - | 10 | 6 | 23 | 12 | F-102312 |
| 27MXL | 27 | C/A | 17.46 | 16.96 | 11 | 16 | 7 | - | 11 | 7 | 23 | 13 | F-102313 |
| 28MXL | 28 | C/A | 18.11 | 17.60 | 11 | 16 | 7 | - | 11 | 7 | 23 | 13 | F-102313 |
| 30MXL | 30 | A/B | 19.40 | 18.90 | 11 | 16 | 7 | - | 11 | 7 | 23 | 13 | F-102313 |
| 32MXL | 32 | A/B | 20.70 | 20.19 | 11 | 16 | 7 | - | 13 | 8 | 26 | 16 | F-102516 |
| 36MXL | 36 | A/B | 23.29 | 22.78 | 11 | 16 | 7 | - | 15 | 10 | 28 | 18 | F-102818 |
| 40MXL | 40 | A/B | 25.87 | 25.36 | 11 | 18 | 7 | - | 17 | 10 | 31 | 20 | F-103120 |
| 48MXL | 48 | A/B | 31.05 | 30.54 | 11 | 18 | 7 | - | 18 | 10 | 35 | 22 | F-103522 |
| 60MXL | 60 | A/B | 38.81 | 38.30 | 11 | 18 | 7 | - | 28 | 20 | 44 | 32 | F-104432 |
| 72MXL | 72 | A/B | 46.57 | 46.06 | 11 | 18 | 7 | - | 30 | 20 | 51 | 36 | F-105136 |
| 84MXL | 84 | A/B | 54.33 | 53.82 | 11 | 18 | 7 | - | 35 | 23 | 61 | 41 | F-106141 |
| 96MXL | 96 | A/B | 62.09 | 61.59 | 11 | 18 | 7 | - | 42 | 28 | 69 | 50 | F-106950 |
| 120MXL | 120 | A/B | 77.62 | 77.11 | 11 | 18 | 7 | - | 56 | 37 | 86 | 66 | F-108666 |
