Ketron® PEEK-GF30 LSG
聚醚醚酮
30% 玻璃纖維增強材料
Quadrant Engineering Plastic Products
產品說明:
KETRON® PEEK-GF30 LSG blue stock shapes are produced from genuine VICTREX® PEEK polymer. This 30% glass fibre reinforced grade combines higher stiffness and creep resistance than KETRON PEEK LSG with a much better dimensional stability. KETRON PEEK-GF30 LSG blue stock shapes have also been successfully type tested for their compliance with both United States Pharmacopeia (USP) and ISO 10993-1 guideline requirements for Biocompatibility Testing of Materials, and they come with full traceability from resin to stock shape. These features, added to an excellent sterilizability by means of steam, dry heat, ethylene oxide, plasma and gamma irradiation, make KETRON PEEK -CA30 LSG stock shapes very suitable for applications in the medical, pharmaceutical and biotechnology markets.
|
填料/增強材料 |
|
|||
|
特性 |
|
|||
|
用途 |
|
|||
|
機構評級 |
|
|||
|
外觀 |
|
|||
|
形式 |
|
|
物理性能 |
額定值 |
單位制 |
測試方法 |
|
密度 |
1.51 |
g/cm3 |
ISO 1183 |
|
吸水率 |
|
|
ISO 62 |
|
飽和, 73°F |
0.10 |
% |
|
|
平衡, 73°F, 50% RH |
0.050 |
% |
|
|
硬度 |
額定值 |
單位制 |
測試方法 |
|
洛氏硬度 (M 計秤) |
100 |
|
ISO 2039-2 |
|
機械性能 |
額定值 |
單位制 |
測試方法 |
|
拉伸模量 |
1.02E+6 |
psi |
ISO 527-2 |
|
拉伸應力 (斷裂) |
12600 |
psi |
ISO 527-2 |
|
拉伸應變 (斷裂) |
3.0 |
% |
ISO 527-2 |
|
彎曲應力 |
22500 |
psi |
ISO 178 |
|
壓縮應力 (5% 應變) |
22500 |
psi |
ISO 604 |
|
熱性能 |
額定值 |
單位制 |
測試方法 |
|
熱變形溫度 (264 psi, 未退火) |
446 |
°F |
ISO 75-2/A |
|
連續使用溫度 2 |
482 |
°F |
|
|
熔融溫度 |
644 |
°F |
ISO 11357-3 |
|
線形熱膨脹系數 - 流動 (73 到 302°F) |
1.7E-4 |
in/in/°F |
|
|
導熱系數 |
|
|
|
