| 產品參數 | |||
|---|---|---|---|
| 品牌 | vieworks | ||
| TDI Stages | 32/64/96/128 | ||
| 分辨率 | 8912 × 128 | ||
| 像素尺寸 | 7.0 ? × 7.0 ? | ||
| 行頻 | 120 ? | ||
| 接口 | Camera Link | ||
| 尺寸 | 90 ㎜ × 90 ㎜ × 38 ㎜ / 500 g | ||
| 數量 | 100 | ||
| 可售賣地 | 全國 | ||
| 型號 | VT-9K7CH80A-128 | ||
| 全系列產品 | VT系列 | |
| Resolution (H × V) | 8912 × 128 | |
| Pixel Size | 7.0 ? × 7.0 ? | |
| Interface | Camera Link | |
| Max. Line Rate | 120 ?? | |
| Pixel Data Format | 8 / 10 / 12 bit | |
| TDI Stages | 32/64/96/128 | |
| Trigger Synchronization | Free-Run, Timed, Trigger Width | |
| Lens Mount | M72 × 0.75 | |
| Dimension / Weight | 90 ㎜ × 90 ㎜ × 38 ㎜ / 500 g | |
| Temperature | Ambient Operating: 0℃ ~ 50℃ (Housing: 10℃ ~ 50℃), Storage: -40℃ ~ 70℃ | |
| Power | 10 ~ 30 V DC | |
| API SDK | Vieworks Imaging Solution 7.X | |
