| 產品參數 | |||
|---|---|---|---|
| 品牌 | vieworks | ||
| 芯片 | Gpixel GMAX3265 | ||
| 分辨率 | 9344 × 7000 | ||
| 像素尺寸 | 3.2 ? | ||
| 幀率 | 4 CH | 35.5 fps @ 8 bit | |
| 接口 | CoaXPress | ||
| 尺寸 | 80 ㎜ × 80 ㎜ × 103 ㎜ | ||
| 色彩 | 黑白 | ||
| 重量 | 750 g (with F-mount) | ||
| 數量 | 100 | ||
| 可售賣地 | 全國 | ||
| 型號 | VC-65MX-C35 I | ||
| 全系列產品 | VC系列 | |
| Sensor | Gpixel GMAX3265 | |
| Resolution (H × V) | 9344 × 7000 | |
| Sensor Size (Diagonal) | 29.9 ㎜ × 22.4 ㎜ (37.4 ㎜) | |
| Pixel Size | 3.2 ? × 3.2 ? | |
| Interface | CoaXPress | |
| Max.Frame Rate | 4 CH: 35.5 fps @ 8 bit | |
| Pixel Data Format | GB Bayer 8 / GB Bayer 10? | |
| Exposure Time (1 ? step) | 12 ? - 60 s | |
| Trigger Synchronization | Free-Run, Hardware Trigger, Software Trigger or CXP | |
| Lens Mount | F-mount, Custom mount available upon request | |
| Dimension / Weight | 80 ㎜ × 80 ㎜ × 103 ㎜, 750 g (with F-mount) | |
| Temperature | Operating: 0℃ ~ 40℃, Storage: -40℃ ~ 70℃ | |
| Power | 11 ~ 24 V DC | |
| PoCXP | 24 V DC, Minimum of two PoCXP cables required | |
| API SDK | Vieworks Imaging Solution 7.X | |
