■性能參數(shù)
| 型 號 | 流量 | 揚程 | 吸程 | 轉速 | 功率 | 泵口徑(mm) | |
| (m3/h) | (m) | (m) | (r/min) | (KW) | 吸入 | 排出 | |
| 25CYZ-A-20 | 3.2 | 20 | 6.5 | 2900 | 0.75 | 25 | 25 |
| 25CYZ-A-32 | 3.2 | 32 | 6.5 | 2900 | 1.1 | 25 | 25 |
| 40CYZ-A-20 | 6.3 | 20 | 6.5 | 2900 | 1.1 | 40 | 32 |
| 40CYZ-A-40 | 10 | 40 | 6.5 | 2900 | 4 | 50 | 40 |
| 50CYZ-A-12 | 15 | 12 | 6.5 | 2900 | 1.5 | 50 | 50 |
| 50CYZ-A-20 | 18 | 20 | 6.5 | 2900 | 2.2 | 50 | 50 |
| 50CYZ-A-30 | 20 | 30 | 6.5 | 2900 | 4 | 50 | 50 |
| 50CYZ-A-35 | 14 | 35 | 6.5 | 2900 | 4 | 50 | 50 |
| 50CYZ-A-40 | 10 | 40 | 6.5 | 2900 | 4 | 50 | 50 |
| 50CYZ-A-50 | 12.5 | 50 | 6.5 | 2900 | 5.5 | 50 | 50 |
| 50CYZ-A-60 | 15 | 60 | 6.5 | 2900 | 7.5 | 50 | 50 |
| 50CYZ-A-75 | 20 | 75 | 6.5 | 2900 | 11 | 50 | 50 |
| 65CYZ-A-15 | 30 | 15 | 6.5 | 2900 | 3 | 65 | 50 |
| 65CYZ-A-32 | 25 | 32 | 6 | 2900 | 5.5 | 65 | 50 |
| 80CYZ-A-13 | 35 | 13 | 6 | 2900 | 3 | 80 | 65 |
| 80CYZ-A-17 | 43 | 17 | 6 | 2900 | 4 | 80 | 65 |
| 80CYZ-A-22 | 40 | 22 | 6 | 2900 | 5.5 | 80 | 65 |
| 80CYZ-A-25 | 50 | 25 | 6 | 2900 | 7.5 | 80 | 80 |
| 80CYZ-A-32 | 50 | 25 | 6 | 2900 | 7.5 | 80 | 80 |
| 80CYZ-A-55 | 60 | 55 | 6 | 2900 | 18.5 | 80 | 80 |
| 80CYZ-A-70 | 60 | 70 | 6 | 2900 | 22 | 80 | 80 |
| 100CYZ-A-20 | 100 | 20 | 6 | 2900 | 11 | 100 | 80 |
| 100CYZ-A-40 | 100 | 40 | 6 | 2900 | 22 | 100 | 100 |
| 100CYZ-A-40A | 100 | 40 | 6 | 1450 | 22 | 100 | 80 |
| 100CYZ-A-65 | 100 | 65 | 6 | 2900 | 30 | 100 | 100 |
| 100CYZ-A-75 | 70 | 75 | 5 | 2900 | 30 | 100 | 100 |
| 150CYZ-A-55 | 170 | 55 | 5 | 2900 | 45 | 150 | 100 |
| 150CYZ-A-65 | 170 | 65 | 5 | 2900 | 55 | 150 | 100 |
| 150CYZ-A-80 | 160 | 80 | 5 | 2900 | 55 | 150 | 100 |
| 200CYZ-A-63 | 280 | 63 | 5 | 1450 | 90 | 200 | 150 |
| 250CYZ-A-50 | 400 | 50 | 5 | 1450 | 90 | 250 | 200 |
| 300CYZ-A-50 | 500 | 50 | 5 | 1450 | 110 | 300 | 250 |
