Lincore ® 60-O美國林肯耐磨焊絲
陜西西安駿焊專業銷售美國林肯耐磨焊絲氣體保護藥芯焊絲堆焊焊絲抗磨損合金焊絲等焊接材料
FLUX-CORED SELF-SHIELDED (FCAW-S) WIRE Welding Positions Typical Applications Flat & Horizontal Bucket lips Crusher hammers Ore chutes Dozer blades Ripper teeth Deposits feature higher alloy levels than to resist both abrasion and moderate impact Can be used at temperatures up to 704°C (1300°F) To be used on carbon, low alloy, manganese, stainless steels and cast iron Deposit is limited to two layers Severe Abrasion ? EN 760 – S A AB 1 Key Features DIAMETERS / PACKAGING Diameter 25 lb (11.3 kg) Steel Spool 50 lb (22.7 kg) in (mm) Coil 0.045 1/16 5/64 7/64 (1.1) (1.6) (2.0) (2.8) ED031131 ED031132 ED031133 ED019887 ED019888 MECHANICAL PROPERTIES(1) Rockwell Hardness (RC ) 55-60 DEPOSIT COMPOSITION(1) %C %Mn %Si %Al %Cr 2 Layers Open Arc 2 Layers w/ 802 Flux 3.7 - 4.3 3.6 - 4.0 0.8 - 0.9 1.0 - 1.1 0.8 - 1.0 1.0 - 1.1 0.3 - 0.4 0.2 -0.3 20.0 - 21.3 17.4 - 18.5 (1) Comb and properties depend upon dilution. Single layer deposit properties depend upon base bl and/or build-up material. TYPICAL OPERATING PROCEDURES Diameter, Polarity ESO - in (mm) Wire Feed Speed Voltage (Volts) Approx. Current (Amps) Deb Rate m/min (in/min) kg/hr (lb/hr) 0.045 in (1.1mm), 西安駿焊DC+ 1 (25) 5.1 10.2 12.7 (200) (400) (500) 21 25 27 125 185 210 1.9 3.7 4.7 (4.1) (8.2) (10.3) 1/16 in (1.6 mm), DC+ 7/8 (22) 5.1 7.6 11.4 (200) (300) (450) 28 31 33 240 300 350 3.4 5.1 7.5 (7.6) (11.2) (16.6) 5/64 in (2.0 mm), DC+ 1-1/4 (32) 3.2 5.1 6.4 (125) (200) (250) 26 30 32 250 350 400 3.4 5.4 6.9 (7.4) (12.0) (15.1) 7/64 in (2.8 mm), DC+ 1-1/8 (30) 1.9 3.2 4.4 (75) (125) (175) 27 30 32 250 340 420 3.4 5.4 7.5 (7.4) (11.9) (16.5) With Recommended Neutral Fluxes 7/64 in (2.8 mm), DC+ 1-1/8 (30) 2.5 3.2 4.4 (100) (125) (175) 30 32 34 295 340 420 4.4 5.4 7.5 (9.6) (11.9) (16.5) NOTE: Deposit thickness limit is two layers unless high travel speed is used to obtain very closely spaced check cracks. Many layers can be used with high travel speed and small bead sizes to ensure close-spaced check cracks. Lincore® 60-0 deposit cross cracks (commonly called cross-checking) on cooling. This is desirable, since cross-cracking of the deposit relieves cooling stresses and prevents spalling.
