Chieftec GPE-400S GPE-500S GPE-600S GPE-700S ATX開關電源Chieftec智拓服務器電源Chieftec ELP-350S ELP-400S ELP-500S ELP-600S ELP-700S ATX開關電源Chieftec智拓電源供應器Chieftec智拓全線工業電源批發及電源維修TEL:13910098771
| Model | ECO 400W |
|---|---|
| Article no. | GPE-400S |
| EAN code | 4710713234178 |
| Weight (without/with package) | 1.28kg /1.42kg |
| AC Input | 230V / 3A |
| Frequency | 50 Hz |
| +5V | 15A |
| +3,3V | 21A |
| +5V & +3,3V combined | 103W |
| +12V1 | 30A |
| +12V2 | - |
| +12V1, +12V2 combined | 360W |
| P.F. | >0,9 |
| -12V | 0,3A / 3,6W |
| +5VSB | 2,5A / 12,5W |
| Maximum Power | 400W |
| 20+4 PIN ATX | 1 |
|---|---|
| 8 PIN EPS(4+4) | 1 |
| 8 PIN PCIe (6+2) | - |
| SATA | 4 |
| MOLEX/FLOPPY | 2 |
| 20+4 PIN ATX | 450 |
|---|---|
| 8 PIN EPS(4+4) | 400 |
| 8 PIN PCIe (6+2) | - |
| SATA | 2x 350/150 |
| MOLEX/FLOPPY | /150 |
| ATX12V Version | ATX 12V 2.4 |
|---|---|
| Efficiency | >85% |
| Dimension (DxWxH) | 140 mm x 150 mm x 86 mm |
| PFC | Active PFC (0,9) (only 230V) |
| Fan | 120mm silent fan |
| Security |
AFC (Automatic Fan speed Control) OPP (Over Power Protection) OVP (Over Voltage Protection) SCP (Short Circuit Protection) SIP (Surge & Inrush Protection) UVP (Under Voltage Protection) |
Chieftec BBS-500S BBS-600S BBS-700S ATX開關電源Chieftec智拓工業電源Chieftec GPE-400S GPE-500S GPE-600S GPE-700S ATX開關電源Chieftec智拓服務器電源Chieftec ELP-350S ELP-400S ELP-500S ELP-600S ELP-700S ATX開關電源Chieftec智拓電源供應器Chieftec智拓全線工業電源批發及電源維修
| Model | CORE 500W |
|---|---|
| Article no. | BBS-500S |
| EAN code | 0753263076120 |
| Weight (Net/Gross) | 1.68kg / 2.47kg |
| AC Input | 100-240V / 8.0A |
| Frequency | 47 - 63Hz |
| +5V | 18A |
| +3,3V | 18A |
| +5V & +3,3V combined | 100W |
| +12V1 | 41A |
| +12V2 | - |
| +12V1, +12V2 combined | 492W |
| P.F. | >0,9 |
| -12V | 0,3A / 3,6W |
| +5VSB | 2,5A / 12,5W |
| Maximum Power | 500W |
| 20+4 PIN ATX | 1 |
|---|---|
| 8 PIN EPS(4+4) | 1 |
| 8 PIN PCIe (6+2) | 1 |
| SATA | 4 |
| MOLEX/FLOPPY | 3/1 |
| 20+4 PIN ATX | 650 |
|---|---|
| 8 PIN EPS(4+4) | 650 |
| 8 PIN PCIe (6+2) | 500 |
| SATA |
1x 500/150/150 1x 500 |
| MOLEX/FLOPPY | 500/150/150/150 |
| ATX12V Version | ATX 12V 2.3 |
|---|---|
| Efficiency | 80+Gold |
| Dimension (DxWxH) | 140mm x 150mm x 86mm |
| PFC | Active PFC |
| Fan | 120mm silent fan |
| Security |
AFC (Automatic Fan speed Control) OPP (Over Power Protection) OVP (Over Voltage Protection) SCP (Short Circuit Protection) SIP (Surge & Inrush Protection) UVP (Under Voltage Protection) |
Chieftec CSN-450C CSN-550C CSN-650C SFX開關電源Chieftec智拓小機箱電源Chieftec BBS-500S BBS-600S BBS-700S ATX開關電源Chieftec智拓工業電源Chieftec GPE-400S GPE-500S GPE-600S GPE-700S ATX開關電源Chieftec智拓服務器電源Chieftec ELP-350S ELP-400S ELP-500S ELP-600S ELP-700S ATX開關電源Chieftec智拓電源供應器Chieftec智拓全線工業電源批發及電源維修
Chieftec GDP-550C GDP-650C GDP-750C ATX開關電源Chieftec智拓工作站電源Chieftec CSN-450C CSN-550C CSN-650C SFX開關電源Chieftec智拓小機箱電源Chieftec BBS-500S BBS-600S BBS-700S ATX開關電源Chieftec智拓工業電源Chieftec GPE-400S GPE-500S GPE-600S GPE-700S ATX開關電源Chieftec智拓服務器電源Chieftec ELP-350S ELP-400S ELP-500S ELP-600S ELP-700S ATX開關電源Chieftec智拓電源供應器Chieftec智拓全線工業電源批發及電源維修
Chieftec CTG-550C CTG-650C CTG-750C ATX開關電源Chieftec智拓工控機電源Chieftec GDP-550C GDP-650C GDP-750C ATX開關電源Chieftec智拓工作站電源Chieftec CSN-450C CSN-550C CSN-650C SFX開關電源Chieftec智拓小機箱電源Chieftec BBS-500S BBS-600S BBS-700S ATX開關電源Chieftec智拓工業電源Chieftec GPE-400S GPE-500S GPE-600S GPE-700S ATX開關電源Chieftec智拓服務器電源Chieftec ELP-350S ELP-400S ELP-500S ELP-600S ELP-700S ATX開關電源Chieftec智拓電源供應器Chieftec智拓全線工業電源批發及電源維修
Chieftec APS-400SB,APS-450SB,APS-500SB BDF-500S Proton 500W,APS-550SB,APS-550CB,APS-600SB,APS-650SB,APS-600CB,BDF-400S,BDF-500S,BDF-1000C,BDF-600S,BDF-650C,BDF-750C,BDF-650C 工控機電源PPS-550FC,PPS-500S,PPS-650FC,PPS-750FC,PPS-1350FC,PPS-1450FC,HPS-350NS,HPS-400NS等Chieftec智拓全線工業電源批發及***電源維修
Chieftec開關電源Chieftec工控機電源Chieftec一體機電源Chieftec工作站電源Chieftec臺式機電源Chieftec服務器電源Chieftec醫療電源Chieftec視頻會議電源Chieftec交換機電源等Chieftec智拓全線工電源批發及***電源維修TEL:13910098771
