Chieftec BDF-400S,BDF-500S,BDF-1000C,BDF-600S,BDF-650C,BDF-750C,BDF-850C 工控機電源PPS-550FC,PPS-500S,PPS-650FC,PPS-750FC,PPS-1350FC,PPS-1450FC,HPS-350NS,HPS-400NS等Chieftec智拓全線工業電源批發及***電源維修TEL:13910098771
| Modell | Proton 500W |
| Artikelnummer | BDF-500S |
| EAN Code | 4710713231269 |
| Gewicht (Netto/Brutto) | 1.55 kg / 1.90 kg |
| AC Input | 115-230V / 10A |
| Frequency | 50-60Hz |
| +5V | 18A |
| +3.3V | 18A |
| +5V & +3.3V combined | 90W |
| +12V 1 | 500W / 41.68A |
| P.F. | >0.9 |
| -12V | 0.3A / 3.6W |
| +5VsB | 2.5A / 12.5W |
| Maximum Power | 500W |
Anschlüsse
| 24PIN ATX | 1 |
| 8 PIN EPS (4+4) | 1 |
| 8 PIN PCIe (6+2) | 2 |
| SATA | 6 |
| MOLEX | 3 |
Kabell?nge
| 24PIN ATX | 450 |
| 8 PIN EPS (4+4) | 550 |
| 8 PIN PCIe (6+2) | 450/150 |
| SATA | 2x 400/150/150 |
| MOLEX | 400/150/150 |
Eigenschaften
| Spezifikation | ATX 12V 2.3 |
| Formfaktor | PS II |
| Wirkungsgrad | 80 PLUS? Bronze |
| Abmessungen (TxBxH) | 140mm x 150mm x 87mm |
| PFC | Aktives PFC (0.9) |
| Lüfter | 120mm leiser Lüfter |
| Sicherheit |
|
Chieftec APS-550CB,APS-600SB,APS-650SB,APS-600CB,BDF-400S,BDF-500S,BDF-1000C,BDF-600S,BDF-650C,BDF-750C,BDF-650C 工控機電源PPS-550FC,PPS-500S,PPS-650FC,PPS-750FC,PPS-1350FC,PPS-1450FC,HPS-350NS,HPS-400NS等Chieftec智拓全線工業電源批發及***電源維修
| AC Input: | 115-230V / 10A |
| Frequency: | 50 - 60Hz |
| +5V: | 22A |
| +3,3V: | 22A |
| +5V & +3,3V combined: | 120W |
| +12V 1: | 24A |
| +12V 2: | 24A |
| +12V 1 & +12V 2 combined: | 540W |
| +12V 3: | N/A |
| +12V 4: | N/A |
| +12V 3 & +12V 4 combined: | N/A |
| P.F.: | >0,9 |
| -12V: | 0,3A / 3,6W |
| +5VSB: | 2,5A / 12,5W |
| Maximum Load: | 600W |
Fixe Kabel
| 24PIN ATX: | 1 |
| SATA: | 6 |
| MOLEX: | 3 |
| Floppy: | 1 |
| 4PIN 12V: | - |
| 8PIN 12V: | - |
| 8PIN (4+4) 12V: | 1 |
| 6PIN PCIe: | 1 |
| 8PIN (6+2) PCIe: | 2 |
Eigenschaften
| Spezifikation: | ATX 12V 2.3 |
| Formfaktor: | PS II |
| Wirkungsgrad: | >85% |
| Abmessungen (TxBxH): | 160 mm x 150 mm x 87 mm |
| PFC: | Active PFC (0,9) |
| Lüfter: | 140mm Lüfter |
| Sicherheit: |
|
| Zertifikate: | 80PLUS BRONZE |
Chieftec APS-400SB,APS-450SB,APS-500SB BDF-500S Proton 500W,APS-550SB,APS-550CB,APS-600SB,APS-650SB,APS-600CB,BDF-400S,BDF-500S,BDF-1000C,BDF-600S,BDF-650C,BDF-750C,BDF-650C 工控機電源PPS-550FC,PPS-500S,PPS-650FC,PPS-750FC,PPS-1350FC,PPS-1450FC,HPS-350NS,HPS-400NS等Chieftec智拓全線工業電源批發及***電源維修
Chieftec APS-400SB,APS-450SB,APS-500SB BDF-500S Proton 500W,APS-550SB,APS-550CB,APS-600SB,APS-650SB,APS-600CB,BDF-400S,BDF-500S,BDF-1000C,BDF-600S,BDF-650C,BDF-750C,BDF-650C 工控機電源PPS-550FC,PPS-500S,PPS-650FC,PPS-750FC,PPS-1350FC,PPS-1450FC,HPS-350NS,HPS-400NS等Chieftec智拓全線工業電源批發及***電源維修
Chieftec開關電源Chieftec工控機電源Chieftec一體機電源Chieftec工作站電源Chieftec臺式機電源Chieftec服務器電源Chieftec醫療電源Chieftec視頻會議電源Chieftec交換機電源等Chieftec智拓全線工電源批發及***電源維修TEL:13910098771
